Doyon LSB516 - Chapter 4 - Technical Data; Technical Characteristics; Electric Specifications; Electric Installation

LMA-A REV.DOC 23/04/08
9
CHAPTER 4
TECHNICAL DATA
4.2 -TECHNICAL CHARACTERISTICS
• Steel body.
• Belt driven.
• Electric motor with 20 speeds.
• Synthetic paint that makes the machine’s surface completely smooth and easier to
clean.
• Stainless steel cylinders.
• Wheel-mounted (LMA620,624,630/LMF624 only).
•
• 4.3 - ELECTRIC SPECIFICATIONS
LMF624/LB516/LSA616/LMA630
Voltage 120V / 240-1ph-3ph / 480 3ph
Speed Variable speed control: 20 speeds
Frequency [Hz] 60HZ
Motor kw .75kw
NEMA configuration 5-15P / 6-15P / 15-15P / L16-20P
4.4 - ELECTRIC INSTALLATION
Doyon’s machines have an electric installation in compliance with the American (ANSI/UL
std. 763), Canadian (CSA std. C22.2 no. 1335.2.14) and European rules.
