CHAPTER 8
CONVEYOR BELTS
8.1 - HOW TO CHANGE THE CONVEYOR BELTS ON THE LSB516 & LMF624
1. Unplug the sheeter.
2. Remove the flour collector.
Unscrew the flour collector fixing screws [picture A, B], and then take the flour
collector off [picture C].
3. Lift the trays and put them in close position [picture D].
A B C
D
