Free-Blowing Device
In areas, in which increased dust particles are to be
expected, a blowing free of the suction tube system
and its suction openings can be necessary.
Free-blowing process of tube system
1. Connect compressed air supply via the free
connection to the three-way ball valve in LSC
control box.
arate the from the tube
system before blowing free of the tube system by
using the three-way ball valve. For this, switch
over the lever of the ball valve from operating
position 0° to position 180°.
3. Blow through the tube system for 6 minutes
through the compressed-air device.
(3 minutes blowing through, 3 minutes suction)
MICRO-SENS
®
2. Sep
A specially developped tube cleaning device for
blowing-through of the suction tube in a lift shaft.
The compressed-air device will be operated with
230V. Only with this efficient compressed-air device
is a building-up of a sufficient pressure volume
possible for best possible cleaning.
The compressed-air device is available at D+H with
the designation Pipe•Clean.
Separate the TITANUS
from tube
system before blowing free of
the tube system, because
otherwise the air flow detector
will be damaged.
MICRO-SENS
®
Titanus Pipe Clean•
Fire recognition
(position 0°)
Free blowing
(position 180°)
Change-over will take place between fire
recognition and free-blowing
.
(position 0°) (position
180°)
4. Place lever of ball valve in 90° position. In this
position, the device will be neither connected
with the tube system nor with the connection of
the compressed-air device.
5. Wait for approx. 20 seconds! Whi
®
rled up dust and
dirt will settle in the lift shaft and can no longer be
removed by using suction via the smoke suction
system.
6. Connect again the blown-free tube system within
further 10 seconds with the
For this, place ball valve again on
position 0°.
MICRO-
SENS
