D+H LSC-M Series User Manual

X.x
5.14
E
D
C
B
A
10
9
8
7
6
5
4
3
2
1
E
D
C
B
A
10
9
8
7
6
5
4
3
2
1
34/48
LSC 44-M4
99.823.35 1.2/06/09
LED lightens
LED “OPERATION”
LED “ALARM”
LED- “MALFUNCTION”
MICRO-SENS is
operable
Alarm release through
detector module
Malfunction in tube system
Tranmission of malfunction
from MICRO-SENS will take
place with a time delay of 2
minutes.
®
®
-
-
orfailure of ventilator
malfunction in detector
module
Content
- for recognition of smoke aerosols
- for monitoring of tube system on break and
choking .
- for transport of air samples to detector module.
Detector module
Airflow detector
Suction unit
(the airflow detector is integrated in detector module)
Put suction tube in tube connection at housing of LSC 44
in case of
variations in
temperature, the
tube will have to be
fixed directly in front
of the device, so that
the tube is not pulled
out of the tube
connection by the
occuring change of
length.
great
Do not use adhesive for connecting suction
tube with tube connection
LED does not lighten
Power supply
disturbed
- no malfunction -
After malfunction has
been eliminated, it can
last up to 2 minutes until
the LED will extinguish.
--no alarm
smoke
suction
device
Type NG23
Smoke Suction System of Type MICRO-SENS
®
Connection of Suction Tube to LSC 44
Display
SHEV-control panel
Tangit
Adhesive agent
