5.9
605 65 0
0°C
12345678
ON SAB
31/48
LSC 44-M4
99.823.35 1.2/06/09
Codification of Control Panel
Switch 1 on ON = Line 2 on group 3
“OFF“
Line 2 is also effective on group 3
In case of alarm of one line, the other line will be set on alarm as well
Factory-setting must be on
Actuate DIP-switch (ON / OFF).
LED’s will light up for 3 seconds in control panel
Switch 1 on OFF =
Switch 2 on ON = Central alarm
Switch 3 on ON = Power failure-CLOSED
ON
Switch 4 on ON =
Switch 5 =
Switch 6 on ON = LED Test / Reset WDT error (Watch Dog Timer)
Switch 7 =
Switch 8 =
Group 3 is independent of line 2
If the power supply breaks down, the drive will close.
Only when group-DIP switch 4 (key operation in CLOSED-direction) =
idle
idle
idle
Bus control
Following functionings can be
set with on
motherboard.
DIP switch S6
Control Panel
