DPVR E3 Polaris Kit - Base Station Calibration; Base Station Calibration Purpose

30
Dead zone
Master
base station
90 degrees
Dead zone
Master
base station
90 degrees
Dead zone
Single base station: The base station
is set as the master. The blue area is
the gaming zone; the gray area is the
dead zone.
Single base station
Dual base stations: The master base
station M covers zones A and C; the
slave base station covers zones A
and B.
Dual base stations
Base station calibration purpose
Base station calibration location calibration: The calibration
process described here allows accurate calculations for the
mounting orientation, height, tilt and relative positioning between
dual base stations. When the base station is mounted and
calibrated once, no more calibration is required as long as the
mounting status (location, orientation, height, tilt) remains
unchanged.
Base station coverage
The coverages of a single base station and dual base stations are
shown below:
Hint: For the positioning kit 180º visual field, please keep facing the
base station while playing the game.
Hint: The 360º coverage is realized only in the overlapped zone
(such as zone A) in the dual base station coverage.
