6.1 Getting Started
(When the DiSEqC Motor parameter is set as USALS)
- Move : Move the dish position to west/east by pressing / buttons.
- Motor Control : Control motor by press button ot the remote.
⍜ Goto Reference : Goto reference by pressing button.
⍜ Set West Limit : Edit & Save west limit by pressing / or buttons.
⍜ Set East Limit : Edit & Save east limit by pressing / or buttons.
⍜ Enable Limit : Enable the saved east and west limit.
⍜ Disable Limit : Disable Limit by pressing button.
⍜ Save : Save the current Setting of USALS system.
- Sat Degree : Displays the current defree of the selected satellite. Edit degree by
pressing / buttons and numeric buttons.
- Position Setting : Select position setting by pressing button.
⍜ Goto Reference : Move the dish to the 0 position.
⍜ Antenna Longitude : Edit antenna longitude by pressing / buttons and numeric
buttons.
⍜ Antenna Latitude : Edit antenna latitude by pressing / buttons and numeric
buttons
- Go To : Save the current setting of USALS Systme.
6.1 Getting Started
(When the DiSEqC Motor parameter is set as 1.2)
- Motor Step : Select Motor Step
- Move : Move the dish position to west/east by pressing / buttons.
- Go To : Go to the position of the saved satellite.
- Motor Control : Control motor by press button ot the remote.
⍜ Recalculate : Recalculate the position of all other saved satellites relative to the
known position.
⍜ Reset System : Reset the position of all saved satellites.
⍜ Goto Reference : Move the dish to the 0 position.
⍜ Set West Limit : Edit & Save west limit by pressing / or buttons.
⍜ Set East Limit : Edit & Save east limit by pressing / or buttons.
⍜ Enable Limit : Enable the saved east and west limit.
⍜ Disable Limit : Disable east and west limit.
⍜ Save : Save the current setting of DISEqC 1.2 system.
<Figure 6-1-5>
