DR All-Terrain FIELD and BRUSH MOWER User Manual

DR

ALL-TERRAIN

FIELD and BRUSH MOWER Safety & Operating Instructions 23
Lubrication
Your DR ALL-TERRAIN FIELD and BRUSH MOWER was greased at the Factory.
The operator needs to lubricate the Wheel Clutch Cable, Brake Cable, Belt Idler Arm
and the Drive Chain, periodically.
Tools & Supplies Needed:
■ Flexible hose grease gun
■ Lithium grease
■ 1/2" wrench or socket (chain cover)
■ FLUID FILM
®
or comparable lubricant
Lubricate the Parking Brake cable and Wheel Drive Clutch cable with FLUID FILM
®
or
comparable lubricant. Spray the lubricant into the cable housing while working the cable
back and forth and few times. This should be done at both ends of the cables (Figure 10).
Perform this lubrication more often in dry and dusty environments.
WARNING! Before performing any maintenance procedure, stop the
engine and disconnect the spark plug wire(s).
Figure 1
0
Lubricate
Lubricate
Lubricate
Brake Cable
Clutch Cable
