DR All-Terrain FIELD and BRUSH MOWER User Manual

44 DR

ALL-TERRAIN

FIELD and BRUSH MOWER Safety & Operating Instructions
Parts List — Brush Deck Assembly
Note: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 164561 Brush Deck, 26 inch
160621 Brush Deck, 30 Inch
02 157261 Spindle Support Assembly
03 160091 Shaft, Spindle
04 150891 Bearing, Ball, .787" Bore
05 151331 Key, Parallel, Round Ends, 1/4" x
3/16" x 7/8"
06 164371 Label, Belt Routing
07 164451 Pulley, V, 8.5" OD, 5L or B Belt
08 164401 Belt Tension Release Lever
09 150831 Idler Arm
10 150711 Bushing, Idler
11 150641 Anti-Wrap Guard
12 151141 Spindle Hub
13 160511 Baffle, 26 inch
160611 Baffle, 30 inch
14 100481 Blade, 26" Air Tip
160891 Blade, 30” Air Tip
15 101771 Blade Washer
Ref# Part# Description
16 151271 Pulley, Flat Idler, 4" x 3/8" Bore
17 150941 Spring, Extension, .112" Wire x
.750" OD x 5" L
18 150721 Attachment Swivel Bushing
19 160071 Nut, Nylon Lock, 5/8" – 18
20 150691 Bolt, HCS, 3/8" – 16 x 2-1/2"
21 110751 Nut, Nylon Lock, 3/8" – 16
22 112391 Washer, Flat, 3/8" USS
23 123211 Bolt, HCS, 5/16" – 18 x 3/4"
24 111521 Bolt, HCS, 3/8" – 16 x 1"
25 150701 Bolt, HCS, 3/8" – 16 x 4"
26 110761 Nut, Nylon Lock, 5/16" – 18
27 145291 Bolt, 5/16" – 18 x 3/4" Carriage
28 112411 Washer, Flat, 5/16" USS
29 150681 Belt, B63K, 5/8" x 66"
30 157271 Belt Cover Assembly
31 143661 Knob, 5/16"
32 165231 Bracket, Belt Tension Lever
33 187351 Bearing, Ball 2 Seal
