DR All-Terrain FIELD and BRUSH MOWER User Manual

32 DR

ALL-TERRAIN

FIELD and BRUSH MOWER Safety & Operating Instructions
Removing the Wheels
Tool Needed:
■ 3/4" socket with extension
1. Block the machine so the
wheel to be removed is off the
ground.
2. Remove the three nuts and
slide the wheel off (Figure 26).
Adjusting the Parking Brake
Tool Needed:
■ 1/2" open-end wrench
To adjust the parking brake,
tighten or loosen the nut shown
in Figure 27. Tightening the nut
will increase pressure and
loosening the nut will decrease
the pressure on the brake pad.
Figure 26
Figure 27
WARNING! Before performing any maintenance procedure, stop the
engine and disconnect the spark plug wire(s).
WARNING! Before performing any maintenance procedure, stop the
engine and disconnect the spark plug wire(s).
Remove Nuts
Adjust Parking Brake
