DR All-Terrain FIELD and BRUSH MOWER User Manual

40 DR

ALL-TERRAIN

FIELD and BRUSH MOWER Safety & Operating Instructions
Chapter 7: Parts Lists, Schematic Diagrams and Warranty
Parts List — Handlebar Assembly
Note: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 150041 Battery Shelf
02 110761 Nut, Nylon Lock, 5/16" – 18
03 150311 Handlebar, Left Hand
04 150301 Handlebar, Right Hand
05 134431 Bolt, HCS, 5/16" – 18 x 1.5"
06 150221 Control Panel
07 110761 Nut, Nylon Lock, 5/16" – 18
08 150391 Shift Lever
09 112441 Washer, 1/2" ID x 3/4" OD x 1/8",
Nylon
10 101341 Battery Pad
11 104831 Battery, 17AH, 12V
12 124511 Clamp, Battery 7-1/8" x 5-1/2"
13a 165171 Wheel Clutch Lever
13b 165181 Brake Lever with Lock
14 180591 Operator Presence Lever w/wire
15 179231 Screw, 25mm
17 150861 Nut, 3/16", Push, Washer Cap
18 164971 Guard, Switch, Operator
Presence
19 151311 Plug, Hour Meter Hole
20 114561 Bolt, HCS, 1/4" – 20 x 1-3/4"
22 110221 Grip, Shift Handle
23 151181 Brake Cable Bracket
24a 164951 Ergonomic Grip, 1" OD, 4.5" L
24b 164961 Plain Grip, 1" OD, 4.5" L
25 165191 Switch, w/Key, Snap-in,
4 Positions (Electric Start)
165201 Switch, w/Key, Snap-in,
2 Positions (Manual Start)
25A 157201 Key, AT2 Ignition Switch
26 150151 Cable, PTO Clutch
26A 152001 Lever, PTO Cable
27 150361 Knob, Blade Engage Cable
Ref# Part# Description
28 111731 Screw, 5/16" – 18 x 1/2"
29 112111 Cable Throttle (B&S)
139051 Cable, Throttle (Kawasaki)
30 151401 Screw, 1/4" – 20 x 3/4", Tri-Lobe
31 112391 Washer, Flat, 3/8" USS
32 110751 Nut, Nylon Lock, 3/8" – 16
33 120301 Screw, 3/8" - 16 x 1-1/2", Tri-Lobe
34 110961 Pin, Roll, 3/16" x 1"
35 181131 Cable, Transmission Brake
36 151431 Pin, Clevis, 3/16" x 3/4"
37 165251 Cable, Traction Drive
38 165271 Wire Harness, Kawasaki, E/S
165291 Wire Harness, B&S, M/S
165281 Wire Harness, B&S, E/S
39 110761 Nut, Nylon Lock, 5/16" – 18
(not illustrated)
40 100241 Shift Arm with Hub
41 110971 Pin, Roll, 3/16" x 1-3/4"
42 150141 Ground Wire (not shown)
Safety Labels
136841 Caution Hot Surface Label
Right Arrow, Briggs
136831 Caution Hot Surface Label
Left Arrow, Kawasaki/Tec.
124371 American Flag Label
127811 Warning: Add Oil Label
153321 DR All Terrain Mower Name Label
179401 Pulley Cover Label
161541 Throttle Control Label
161521 Control Panel Label
136491 Danger, Deck Label
164371 Blade Belt Routing
