DR PREMIER 26" - Drive Assembly Parts List

26 DR
®
PREMIER 26" ALL-TERRAIN MOWER
Parts List – DRIVE ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 38883 Mount, Engine, W/ Labels
2 33332 Nut, Nylon Lock, Flanged, 5/16-18
3 35281 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X
3/4", GR5 ZP
4 36356 Transaxle, 3spd, W/ Switch, Peerless
5 35302 Wheel Assembly, Snow Hog, 4.8-8,
Keyed Hub
6 11114 Pulley, V, 7" OD 4l/A Belt
7 36639 Bracket, Axle
8 24739 Idler Arm, Drive
9 15111 Bushing, 0.390" ID X 0.620" OD X 1.585"
L
10 10850 Pulley Flat Idler 3"
11 35110 Belt, Ak32, 1/2" X 34"
12 37063 Pulley, Engine
13 28990 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X 1",
GR5 ZP
14 33333 Nut, Nylon Lock, Flanged, 3/8-16
15 35303 Guide, Belt, Traction Drive
16 37064 Mount, Cable
17 11238 Washer, Flat, 1/4"
18 11150 Bolt, SHCS, 1/4-18 X 3/4", Black Oxide
19 33350 Bolt, Hex, Flange, 3/8-16 X 2"
20 35051 Spacer, Idler
21 35261 Spring, Extension
22 34423 Pulley, Keyed, A V-Belt, 2.5" OD, 1" Shaft
23 11124 Snap Ring, External, 5/8"
24 11126 Ring, Retaining, 3/4" E-Clip
25 19130 Washer, Flat, .469" X 1.62" X .25"
26 22252 Washer Lock 7/16" Split, ZP
27 10636 Square Key
28 37730 Bracket, Cover
29 35145 Bracket, Shift, Transmission
Ref# Part# Description
30 37750 Bolt,HHCS,1/4-20 X .50, Flanged, GR5,
ZP
31 38884 Rail, Frame, Left
32 38885 Rail, Frame, Right
33 37088 Guide, Belt, Engine
34 35023 5/16-18 X .75", HHCS, Flange, GR5, ZP
35 38945 Washer, Flat , .75" X 1.125" X .012"
36 16413 Nut, Nylon Lock, 3/8-16, Low Profile
37 38960 Engine, B&S, 10.5hp MS, 50st, W/Labels
38958 Engine, DR, 13.3TQ, 340cc, E/S,
50st/CE, W/Labels
38 38952 Bolt, HHCS, 3/8-16 X 2.25", Flanged,
GR8, ZP
39 22324 Bolt, HCS, 7/16-20 X 2.75", GR8, YZP
(B&S 10.5 Only)
37132 Bolt, HCS, M10 X 1.25 X 50, CL 10, ZP
(DR 13.3 Only)
40 10119 Key, Square, 3/16" X 2"
41 14232 Key, Square, 1/4" X 1.00"
Not Shown
13758 Label, Check Oil
13683 Label, Caution, Hot Surface
DR Engine Parts Not Shown
38889 Drain Tube, w/Plug
B&S Engine Parts Not Shown
34331 Muffler Guard, B&S
34332 Screws, guard, B&S
34333 Deflector, Briggs
34334 Static Cover, Briggs
34335 Screw, B&S, static cover
