DR PREMIER 26" - Handlebar Assembly Parts List; Chapter 6: Parts Lists, Schematic Diagrams and Warranty

24 DR
®
PREMIER 26" ALL-TERRAIN MOWER
Chapter 6: Parts Lists, Schematic Diagrams And Warranty
Parts List - HANDLEBAR ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 33332 Nut, Nylon Lock, Flanged, 5/16-18
2 10913 Bolt, Carr, 5/16-18 X 1.5, ZP
3 35281 Bolt, Hex, Flange, Tri Lobe, 3/8-16 X 3/4,
GR5 ZP
4 38923 Handlebar, Left W/Label
5 34429 Handlebar, Right
6 38886 Control Panel, W/Labels
7 16496 Grip, 1.00"
8 35106 Lever, Shift
9 35107 Mount, Shift Lever
10 15036 Knob, Shift Lever
11 11173 Bolt, HCS, Serrated Flange 5/16-18 X
.50"
12 35290 Bolt Shoulder, 1/2" X 5/8" L, 3/8-16
13 33333 Nut, Nylon Lock, Flanged, 3/8-16
14 35131 Cable, Shift
Ref# Part# Description
15 35118 Cable, Traction Drive
16 15131 Plug, Hour Meter Hole, 2" X 1-1/4"
17 37051 Collar, Lever, 1", Threaded
18 17923 Screw, SHCS, M6-1 X 25mm
19 15049 Screw, 8-32 X 1/2"
20 38890 Lever, Blade Engagement, Zero Lock,
160mm
21 38924 Lever, Traction Drive, W/ Label
22 35317 Cable, Throttle, 61" (10.5 B&S)
13905 Cable, Throttle, 50" (13.3 Rato)
23 38512 Label, Blade Engagement, Lever
24 37751 Label, Control Panel
25 35274 Label, Control Panel, Front
26 37055 Label, Traction Drive
27 11214 Cable Tie, 7-1/2" Long
