36 DR
®
TRIMMER/MOWER
Chapter 6: Parts Lists, Schematic Diagrams And Warranty
Parts List - Handlebar Assembly - SPRINT
and PRO Models
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
03 143971 Cable, Throttle, Reverse Throw, B&S
04 112381 Washer, Flat, 1/4", USS
05 113081 Ignition Switch, Key, E/S, w/805
Hardware
06 174561 Handlebar, Lower, Black
07 144641 Bolt, Carriage, 5/16"-18 x 3", GR 2, ZP
08 110761 Nut, Nylon Locking, 5/16"-18
09 147551 Handlebar, Upper, Black
179191 Handlebar, Upper, Black, w/Grip
10 123361 Bolt, 5/16"-18 x 1-1/4", HCS, GR 5, ZP
11 174531 Bracket, key switch
12 110731 Nut, Nylon Locking, 1/4"-20
13 101451 Bolt, 1/4"-20 x 1-1/2", HHCS, GR 2, ZP
14 112371 Washer, Flat, #10, USS
15 143681 Bracket, Cable, Trimmer Head Engage,
Handlebar
17 143671 Stop, Bail Bar
18 165331 Grip, Handlebar, Foam
19 143931 Spring, C, .720" OD x .063" Wire,
Handlebar Adjuster
Ref# Part# Description
20 143661 Knob, Handlebar, 5/16"-18
21 191351 Handlebar Adjuster, Inside
22 143731 Handlebar Adjuster, Outside
22.1 145801 Handlebar Adjuster Assembly
23 112141 Cable Tie, Nylon, Black, 7-1/2"
25 114561 Bolt, 1/4"-20 x 2", HCS, GR 2, ZP
26 143981 Cable, Trimmer Head Engage
30 214661 O-Ring
109 143651 Bail Bar
110 143901 Knob, Bracket, PTA
Lever
112 143881 Lever, PTA
113 143891 Bracket, PTA
Lever, Handlebar
116 144001 Cable, PTA
117 118691 Nut, Head Engage Cable
Not Illustrated
188241 Wire Harness, w/adapter, B&S
