CONTACT US AT www.DRpower.com 7
Tape
Figure 2
Specifications
MECHANICAL SPECIFICATIONS
6.25 Sprint 6.75 PRO 6.75 PRO-XL Self Propelled
Engine
Briggs & Stratton Briggs & Stratton Briggs & Stratton
Series
Quantum Quantum Quantum
Torque
6.25 ft. lbs.(8.5 Nm) 6.75 ft. lbs.(9.1 Nm) 6.75 ft. lbs.(9.1 Nm)
Fuel Capacity
1.5 Quarts (1.4 Liters) 1.5 Quarts (1.4 Liters) 1.5 Quarts (1.5 Liters)
Oil Capacity
1.25 pints (0.59 Liter) 1.25 pints (0.59 Liter) 1.25 pints (0.59 Liter)
Air Filter
Pleated Paper Pleated Paper Pleated Paper
Oil Filter
NA NA NA
Wheels
14" Resin 16" Resin 12" Steel Spokes
Frame
14-Gauge Steel 14-Guage Steel Cast Aluminum
Cutting Width
20" 20" 20"
Cutting Height
1-1/2" to 4" 1-1/2" to 4" 1-1/2" to 4"
Machine Width
23" 23" 20 1/2"
Machine Weight
68 lbs. Manual Start,
75 lbs. Electric Start
70 lbs. Manual Start,
77 lbs. Electric Start
88 lbs. Electric Start
Unpacking the DR TRIMMER/MOWER
Tools Needed:
Utility Knife
5/8" Wrench
Wire Cutters
1. Position the Shipping Box at floor level in a clean flat area with the text on
the side of the Box right side up (Figure 2).
2. With a Utility Knife, cut the Tape that secures the Box Flaps at both ends and
along the center.
Parts Supplied in Box (Figure 3):
DR TRIMMER/MOWER
Trimmer Wheels
Product Package
Trimmer Cord Pack
Mow-Ball™
Two Keys, for electric-starting models (located just below the Bail Bar
Spring of the Trimmer)
Compare the contents of the Shipping Box with the “Parts Supplied” list above.
If you have any questions please contact us at www.DRpower.com or call 1-800-
DR-OWNER (376-9637) for assistance.
Stabilize the shipping box at floor level in a clean flat area before attempting to unpack the Trimmer/Mower. For your safety we
recommend you have two people for the following procedures.
Figure 3
Product
Package
Trimmer
Cord
Pac
DR
Trimmer/
Mower
Keys
Wheel
Bail Bar
Spring
Mow-
Ball™
