40 DR
®
TRIMMER/MOWER
Parts List - Main Frame Assembly - All Models
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
04 112381 Washer, Flat, 1/4", USS
08 110761 Nut, Nylon Locking, 5/16"-18
12 110731 Nut, Nylon Locking, 1/4"-20
28 190071 Frame, Steel, Orange (SPRINT, PRO)
180421 Frame, Drilled, Aluminum, Orange
(PRO-XL SELF-PROPELLED)
45 180811 Washer, Lock, 3/8"
47 111551 Bolt, 3/8"-24 x 3/4", HHCS, GR 2, ZP
49 151401 Screw, 1/4"-20 x 3/4", Tri-Lobe, ZP
50 111581 Bolt, 5/16"-18 x 1", HHCS, GR 2, ZP
51 143941 Spring, Ext., .50" OD x .063" Wire
52 114431 V-Belt, 1/2" x 45", 4L450
53 110751 Nut, Nylon Locking, 3/8"-16
54 144091 Pulley, Idler #2, 2-5/8" OD
55 143771 Shield, Outer, Lower
56 119191 Pulley 4", V-Belt
60 146811 Clip, Mounting, Inner Lower Shield,
(PRO-XL SELF-PROPELLED)
143801 Clip, Mounting, Inner Lower Shield,
(SPRINT, PRO)
143811 Shield, Inner, Lower, steel
(SPRINT, PRO)
179511 Shield, Bottom (PRO-XL SELF-PROPELLED)
62 180131 Bolt, 1/4"-20 x 1", Tri-Lobe, ZP
63 143871 Battery, 12 V, 2.9 Ah
64 143861 Pad, Battery, 1.38" x 7.0"
65 143851 Clamp, Battery, Plastic
66 SPRINT Models
241401 Engine, 6.25 TQ, B&S, M/S, CA
241411 Engine, 6.25 TQ, B&S, E/S, CA
241051 Engine, 6.25 TQ, B&S, M/S, EMI
241061 Engine, 6.25 TQ, B&S, E/S, EMI
PRO Models
241421 Engine, 6.5 TQ, B&S, M/S, CA
241431 Engine, 6.5 TQ, B&S, E/S, CA
241071 Engine, 6.5 TQ, B&S, M/S, EMI
241081 Engine, 6.5 TQ, B&S, E/S, EMI
Ref# Part# Description
66 PRO-XL SELF-PROPELLED Model
?????? Engine, 6.75 TQ, B&S, E/S
?????? Engine, 6.75 TQ, B&S, E/S, CA
67 114921 Bracket, Belt Retainer
68 118731 Nut, Nylon Locking, 10-24
69 143831 Bracket, Clutch, Deck
70 113071 Pulley, Idler #1, 2-1/4" Diameter
71 143521 Rod, Brake Connecting
72 134431 Bolt, 5/16"-18 x 1-1/2" HCS
73 143751 Washer, Nylon, .505" ID x 1" OD
74 143601 Stand-off, Clutch Arm
75 143581 Arm, Clutch
85 146801 Guide, Engine Pulley, Belt
(PRO-XL SELF-PROPELLED)
143821 Guide, Engine Pulley, Belt (Sprint)
98 152501 Bolt, 1/4"-20 x 3/4" HCS
99 146821 Rod, Debris Guard
(PRO-XL SELF PROPELLED)
143791 Rod, Debris Guard (SPRINT)
100 147581 Screw, 10-24 x 1/2", Type B
(PRO-XL SELF PROPELLED)
144511 Bolt, Carriage, 10-24 x 5/8"
(SPRINT, PRO - used with item 68)
107 143781 Debris Guard (SPRINT, PRO)
114 152141 Rivet, Ratchet, 1/4" OD
(PRO-XL SELF-PROPELLED)
115 146791 Wear Strip (PRO-XL SELF PROPELLED)
Not Illustrated:
114681 Bolt, 1/4"-20 x 1-1/4" HCS
100771 E-Clip, Clutch Cable
(SPRINT, PRO)
Labels:
127811 Warning, Add Oil
136491 Danger
148221 Danger Head Rotation
148231 Safety Icons
240641 Name, TR2 (SPRINT, PRO)
215001 PTA (SPRINT, PRO)
153081 Bail Bar
193201 Start, Key Bracket
