44 DR
®
TRIMMER/MOWER
Parts List - Axle Assembly – PRO-XL SELF- PROPELLED
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
02 190541 Sleeve, Axle
08 110761 Nut, Nylon Lock, 5/16"-18
12 110731 Nut, Nylon Lock, 1/4"-20
14 112371 Washer, Flat, #10, USS
46 179581 Belt, Transmission Drive, 3/8" x 20"
50 111581 Bolt, 5/16"-18 x 1" HCS
57 175601 Pulley, Transmission Drive, 2-3/4"
68 118731 Nut, Nylon, Lock, 10-24
76 193801 Transmission
77 189791 Ring, Retaining, 10mm x 1mm Thick
78 112441 Washer, .50" ID x .75" OD x .125" Thick,
Nylon
79 179121 Screw, 1/4"-20 x 1/2", Tri-Lobe
80 213101 Ring, Retaining, .5" Shaft
81 143751 Washer, .505" ID x 1.00" OD
82 179611 Clutch, Wheel
83 152331 Nut, Nylon, Lock, 7/16"-20, Low Profile
84 240321 Wheel Kit, Left and Right
86 193811 Sprocket, Transmission, 10 Tooth
Ref# Part# Description
87 189591 Spring, Ext., Transmission Tension
88 179631 Bracket, Anti-Rotation
89 179591 Pulley, Transmission, 4"
90 152501 Bolt, 1/4"-20 x 3/4" HCS
91 179551 Bearing, w/Flange
92 175521 Bolt, Eye, 10-24 x 1/2"
93 193791 Axle, w/Woodruff Key
94 193821 Sprocket, Wheel, 40 tooth
95 179681 Plate, Axle, Mounting, Left
96 180841 Plate, Axle, Mounting, Right
97 179621 Chain, #35, 57 Links plus Master Link
99 213181 Key, Woodruff, 1/8" x 1/2"
Not Illustrated
189581 Key, Woodruff, 5/32" x 5/8"
