46 DR
®
TRIMMER/MOWER
Parts List - Mow Ball™ Assembly - All Models
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
14 112371 Washer, Flat, #10 USS
30 213081 Bolt, Flat Head, 5/16"-18 x 2.75" w/Patch
31 143991 Spring, Ext., .500" OD x .049" Wire,
Brake Return
32 143511 Brake Arm Assembly
33 121521 Washer, Axle, .750" OD x .380" ID
34 114781 Screw, Pan Head, 10-24 x 5/8", Slotted,
GR 2
35 229181 Plate, Lower, w/Bearing
36 143491 Plate, Bearing, Upper
37 143921 Bearing, Ball, w/Snap Ring
38 143531 Pulley, V-Belt, 3-1/2"
39 144631 Bolt, 3/8"-16 x 4-3/4", HHCS, GR 5, ZP
40 144101 Mow Ball™, Nylon
Ref# Part# Description
41 235151 Plate, Line Spacer
42 143551 Standoff, Line Spacer Plate, T
43 143541 Plate, Back-Up
44 144701 Bolt, Serrated Flange, 5/16"-18 x 3/4",
HHCS, GR 5, ZP
118 147181 Bearing Housing Assembly w/Brake and
Belt
119 160321 Head Assembly, Complete
REF 145311 Cord, 23" long
Not Illustrated:
152361 Tool, Head Locking
240601 Kit, Tree Guard
