DR Trimmer/Mower Sprint - Parts List

DR
®
TRIMMER/MOWER
™
Safety & Operating Instructions 24
Parts List
Please refer to the schematic drawings on pages 26-27.
Ref# Part# Description
01 143741 Axle Assembly
02 143541 Backup Plate
03 143651 Bail Bar
04 143671 Bail Bar Stop
05 143851 Battery Bracket
06 143861 Battery Pad
07 143871 Battery, 12 V, 2.9 Ah,
Rechargeable
08 143501 Bearing Plate, Lower
09 143491 Bearing Plate, Upper
10 143921 Bearing, Cutter Drive
11 143591 Belt Guide, Clutch Arm
12 143821 Belt Guide, Engine Pulley
13 144511 Bolt, Carriage, 10-24 x 5/8", Gr
2, YZ, Debris Guard Rod, Left
14 144541 Bolt, Carriage, 5/16" - 18 x 3", Gr
2, YZ, Right Handlebar Adjuster
15 114691 Bolt, HHCS, 1/4" - 20 x 1/2", Gr
2 ZP, Bail Bar Stop
16 114681 Bolt, HHCS, 1/4" - 20 x 1-1/4",
Gr 2 ZP, Switch Bracket
17 111481 Bolt, HHCS, 1/4" - 20 x 1-3/4" Gr
2 ZP, Throttle Control
18 119831 Bolt, HHCS, 1/4" - 20 x 3/4", Gr
2 ZP, Inner Lower Shield
19 144691 Bolt, HHCS, 3/8" - 16 x 4-3/4",
Line Plate Stack, 6 or 7
20 111551 Bolt, HHCS, 3/8" - 24 x 3/4", Gr
2 ZP, Engine Pulley
21 127701 Bolt, HHCS, 5/16" - 18 x 1-1/2",
Gr 5, Clutch Assembly to Frame
22 111581 Bolt, HHCS, 5/16" - 18 x 1", Gr 2
ZP
23 120101 Bolt, HHCS, Slotted, 10 - 24 x
5/8", Gr 2, Brake Arm Pivot
24 144701 Bolt, HHCS, Serrated Flange-
Head, 5/16" - 18 x 3/4", Gr 5 YZ,
Bearing Housing to Frame
Ref# Part# Description
25 143511 Brake Arm Assembly
26 143521 Brake Connecting Rod
27 112141 Cable Tie, Nylon, Black, 6"
28 143981 Cable, Clutch
29 144001 Cable, PTA
30 143971 Cable, Throttle, Reverse Throw
31 110871 Clevis Pin, 1/4" x 5/8", Clutch
Return Spring Anchor
32 144731 Clip, Cable, Double, 7/8", Upper
Handlebar, Right
33 143801 Clip, Mounting, Inner Lower
Shield
34 143581 Clutch Arm
35 143601 Clutch Arm Standoff
36 143831 Clutch Cable Bracket, Deck
37 143681 Clutch Cable Bracket, Handlebar
38 119551 Collar, Wheel Retaining, 1/2",
I.D.
39 143781 Debris Guard
40 143791 Debris Guard Rod
41 100771 E-Clip, Clutch Cable, Deck
Clutch Cable Bracket
42 Engine
43 144111 Washer, Belleville, .406" ID x 1"
OD x .062 THK", Engine Pulley
44 143471 Frame, Trimmer - Steel
45 143721 Handlebar Adjuster, Inside"
46 143731 Handlebar Adjuster, Outside
47 143701 Handlebar, Lower, White
48 143711 Handlebar, Upper, White
49 113081 Ignition Switch E/S
50 143661 Knob, Handlebar, Flush Nut
51 143901 Knob, PTA Handlebar Clamp
52 143551 Line Plate Stand Off
53 143571 Line Spacer Plate
54 144101 Mow Ball, Nylon
