INFINITY COCKPIT QUICK REFERENCE GUIDE |9
THIS GUIDE IS INTENDED
FOR REFERENCE
ONLY. REFER
TO
INSTRUCTIONS FOR USE
MANUAL.ADDITIONAL INFORMATION
AUDIO PAUSE KEY
This key is located to the right of the rotary knob.
Pauses acoustic alarm signals for two minutes.
Note: Quiet Mode is Activated – If a new alarm condition with a priority
higher than the currently paused alarm occurs, a truncated alarm tone
sounds. In addition, the alarm is represented by visual alarm signals corre-
sponding to the alarm priority. If the new alarm is of lower priority than the
paused alarm, the new alarm condition is only represented by a visual alarm
signal. No acoustic alarm tones sound.
If Quiet Mode is Deactivated - Any new alarm condition breaks through the
Audio Pause period with full acoustic and visual alarm annunciation.
TO CALIBRATE THE C700 / 500 SCREEN
1. Press the rotary knob for 30 sec. until the Calibrate Touch
Screen popup appears. (Requires several seconds)
2. Select the Calibrate button in the popup or press the rotary
knob again to access the calibration screen.
3. Follow the onscreen prompts
4. Depress the circles until they turn Dark Blue.
