Dräger Infinity Delta Quick Reference Guide

© 2014 Draeger Medic al , Inc .
INFINITY DELTA / KAPPA QUICK REFERENCE GUIDE |10
THIS GUIDE IS INTENDED FOR REFERENCE ONLY. REFER TO INSTRUCTIONS FOR USE MANUAL.ADDITIONAL INFORMATION
Fixed Keys
Key
Function
ALARM SILENCE
Silences the active alarm tone for 2 minutes or
cancels the Alarm Silence
*Note: Silences the active alarm tone for 1 mi-
nute when Backwards Compatibility is Enabled,
subsequent key press resets the timer to 1 mi-
nute
ALARM LIMITS
Opens a table from which you can set upper and
lower alarm limits
ALL ALARMS OFF
Suspends all alarms for a pre- selected time or
cancels the suspension
CODE
Activates a set of monitor functions for urgent
care
DISCHARGE
Accesses the Discharge menu.
*Note: Press the Discharge key a second time to
discharge the patient.
MAIN SCREEN
Activates the main screen.
RECORD
Starts/stops a timed recording.
PRINT SCREEN
Prints the currently displayed screen to a net-
work laser printer.
NBP START STOP
Starts or stops a non-invasive blood pressure
(NBP) measurement.
FAST ACCESS
Displays the Fast Access menu.
MARK
Creates and stores a waveform and correspond-
ing vital signs with a time stamp that may be
viewed in the Alarm History and Event Recall.
FREEZE (DELTA XL
ONLY)
Freezes the waveforms
MENU
Activates the main menu.

Dräger Infinity Delta Specifications

General

Display Size	10.4 inch
Resolution	800 x 600 pixels
Battery Type	Lithium-ion
Parameters Monitored	ECG, SpO2, NIBP, Invasive Blood Pressure, Temperature, CO2, Cardiac Output
ECG	Yes
SpO2	Yes
NIBP	Yes
Invasive Blood Pressure	Yes
Temperature	Yes
CO2	Yes
Cardiac Output	Yes
Power Supply	100 to 240 V AC, 50/60 Hz
Connectivity	WLAN
Operating Temperature	0 to 40 °C
Storage Temperature	-20 to 60 °C
Humidity	15 to 95 % relative humidity, non-condensing
Alarms	Audible and visual alarms
