INFINITY DELTA / KAPPA QUICK REFERENCE GUIDE |18
THIS GUIDE IS INTENDED FOR REFERENCE ONLY. REFER TO INSTRUCTIONS FOR USE MANUAL.ADDITIONAL INFORMATION
TRENDS
1. Press FAST ACCESS fixed key.
2. Use Rotary knob to highlight Trend Graph or Trend Table,
click.
3. Use Rotary knob to highlight interval time, click.
4. Use Rotary knob to set desired interval, click.
5. Use Rotary knob to highlight Report, click to print Trends.
TRENDS, GRAPHS, WAVEFORM & ECG REPORTS
Menu Item
Description
Setting
Options
ECG Report
Prints Rest ECG Report
x Available only if with a 12 lead pod,
Aries SW option installed, & monitor
connected to ICS with REST ECG re-
port option.
x
If not connected to ICS, one can only
print ECG waveform report.
Click on the
printer icon to
request a re-
port or while in
ECG Menu,
click on report
Timed
Waveforms
Prints timed recording report to laser
printer
Continuous
Waveforms
Prints continuous recording report to la-
ser printer for all currently monitored
waveforms
Click on printer
icon to request
report
Waveform
Delay
Determines the amount of pre-event
data included in the time recording
6, 10, 15a
Waveform
Duration
Determines the length of timed report
10, 20a
Trend Graph
Prints a graphical report
Click on printer
icon to request
Trend Table
Prints a tabular trend report
Click on printer
icon to request
Trend Dura-
tion
Determines length of graphical trend re-
port. Corresponds to the Hours setting
at the bottom of Trend Graphs table.
1, 2, 4, 8, 12,
12, 24 hrs.
