INFINITY M540 QUICK REFERENCE GUIDE |18
THIS GUIDE IS INTENDED FOR REFERENCE ONLY. REFER TO INSTRUCTIONS FOR USE MANUAL.ADDITIONAL INFORMATION
TO SELECT PACER DETECTION
1. Touch Heart rate parameter box > touch Settings tab
2. Touch > ECG 2 tab
3. Touch Pacer detection – On / or Off.
TO ADJUST QRS DETECTION THRESHOLD
1. Touch Heart rate parameter box > touch Settings tab.
2. Touch > ECG 2 tab
3. Select Normal or Low QRS Threshold
*Note – Low detects QRS complexes of low amplitude.
TO RELEARN ECG
Not available in Neonatal mode
1. Touch Heart rate parameter box.
2. Touch Settings tab > ARR tab > Relearn.
NIBP - Non-Invasive Blood Pressure
TO START A NIBP SINGLE MEASUREMENT
1. Press the NIBP Start / Stop fixed key .
o Pressing the key again stops the measurement.
o NIBP inflation limit settings - Adult, pediatric, and neonatal
- can be selected in NIBP parameter box > Settings tab
TO SET INTERVAL TIME
1. Touch NIBP parameter box.
2. On Settings tab, Touch the Interval time button and select
desired time interval.
3. Press NIBP key to initiate cycling.
o An interval timer bar appears in the parameter box between
interval measurements and indicates interval timed BP’s are
in use.
