INFINITY M540 QUICK REFERENCE GUIDE |22
THIS GUIDE IS INTENDED
FOR REFERENCE
ONLY. REFER
TO
INSTRUCTIONS FOR USE
MANUAL.ADDITIONAL INFORMATION
12 Lead Monitoring
Requires an additional 4 lead wire set be added to an existing 6
lead set, and 12 lead option must be enabled.
TO OBTAIN A DIAGNOSTIC 12-LEAD REPORT
1. Touch ECG parameter box > touch Settings tab.
2. Press Rest ECG setup, enter patient gender and race.
3. Press Rest ECG report.
OR
1. Press Menu function key.
2. Press Rest ECG report.
Invasive Pressures
Connect Dual Hemo MCable, Quad Hemo or Hemopod to gray Inva-
sive Blood Pressure connecter on end of M540. Attach Transducer
to Transducer adapter cable. Assign correct label for invasive line.
TO ASSIGN/CHANGE A PRESSURE LABEL
1. Press Menu function key.
2. On Main settings tab, touch Label IBP.
3. Touch the new pressure name (ART, CVP, PA, ICP, GP1, GP2,
GP3, etc.)Each label can only be used once.
TO ZERO AN INDIVIDUAL TRANSDUCER
1. Prior to zeroing, align the transducer stopcock to the level of
the heart (phlebostatic axis point, fourth intercostal space at
mid-axillary line), or other appropriate zero level depending on
parameter, i.e. ICP.
2. Touch parameter box of the desired pressure to zero.
3. Touch Settings tab.
4. Open that transducer to air and off to the patient.
5. Press Zero.
To Next Page
