Dräger Infinity M540 - Page 155

Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 155
Alarms
IBP M pediatric
Increment:
1 mmHg or
0.1 kPa
On Upper: –24 to +300 mmHg
–3.2 to +40.0 kPa
Lower: –25 to +299 mmHg
–3.3 to +39.9 kPa
–80mmHg
(10.7 kPa)
for GP1 M to
GP4 M,
ART M, LV M
–20mmHg
(2.7 kPa) for
LA, ICP, CVP
–17mmHg
(2.3 kPa) for
PA M, RV M
–12mmHg
(1.6 kPa) for
RA
– 50 mmHg
(6.7 kPa)
for GP1 M
to
GP4 M,
ART M
– 40 mmHg
(5.3 kPa)
for LV M
–7mmHg
(0.9 kPa)
for PA M,
RV M
–2mmHg
(0.3 kPa)
for RA, ICP
–0mmHg
(0.0 kPa)
for LA,
CVP
Off
IBP M neonate
Increment:
1 mmHg
or 0.1 kPa
On Upper: –24 to +300 mmHg
–3.2 to +40.0 kPa
Lower: –25 to +299 mmHg
–3.3 to +39.9 kPa
–85mmHg
(11.3 kPa) for
GP1 M to
GP4 M, ART
M,
–80mmHg
(10.7 kPa)
for
LV M
–20mmHg
(2.7 kPa) for
LA, ICP, CVP
–17mmHg
(2.3 kPa) for
PA M, RV M
–12mmHg
(1.6 kPa) for
RA
– 40 mmHg
(5.3 kPa)
for GP1 M
to
GP4 M,
ART M,
LV M
–7mmHg
(0.9 kPa)
for PA M,
RV M
–2mmHg
(0.3 kPa)
for RA, ICP
–0mmHg
(0.0 kPa)
for LA,
CVP
Off
Parameter Alarm
default
status
Alarm limit range Upper limit
defaults
Lower limit
defaults
Archive
default
setting
