Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 213
ECG, arrhythmia, and ST segment
Leads – Three electrodes: I, II, III
– Five electrodes: I, II, III, aVR, aVL, aVF, V
– Six electrodes: I, II, III, aVR, aVL, aVF, V, V+
– Six electrodes (with TruST activated): I, II,
III, aVR, aVL, aVF, dV1, V2, dV3, dV4, V5,
dV6
– Ten electrodes: I, II, III, aVR, aVL, aVF, V1
to V6
– Default for lead 1: II
– Default for lead 2: V (with TruST and a 6-
wire lead set plus a 4-wire lead set, the
default is: V2)
– Default for lead 3: aVF
Assigns specific leads for
each waveform depending on
which lead mode is selected.
Size [mV/cm] 0.25, 0.5, 1 (default), 2, 4, 8 mV/cm Sets the scale of individual
ECG waveforms.
Color Red, green (default), blue, yellow, light blue,
purple, orange, white
Determines the color of the
waveforms and parameter
labels and values.
Settings 2 page
Selection Available settings Description
