Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 245
Impedance respiratory rate (RRi)
– For neonates, place the RA and LA electrodes
at the midaxillary line. Position the LL electrode
below the diaphragm and umbilicus. Avoid the
liver area and ventricles of the heart to prevent
blood flow artifact.
495
328
AHA electrode
(neonates)
placement
