Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 249
Impedance respiratory rate (RRi)
In case of false apnea alarms, it is advised to
observe the patient's breathing pattern (belly or
chest), and reposition electrodes accordingly, or to
adjust the detection threshold manually.
Resp. marker – On
– Off (default)
Superimposes a vertical line on
the respiration waveform when
a breath is detected (see
page 246).
Resp. monitoring – On (default in neonatal mode)
– Off (default in adult/pediatric mode)
Activates/deactivates
respiration monitoring.
Color Red, green, blue, yellow, light blue, purple,
orange, white (default).
Determines the color of the
waveforms, parameter labels,
and values.
Settings 2 page
Coincidence
detect
–On
– Off (default)
Determines whether or not you
are alerted when the respiratory
rate is within 20% of the heart
rate, which is an indication that
the M540 is counting heart
beats as respiration.
RRi apnea time [s] Off, 10, 15 (default), 20, 25, 30 seconds Determines how long an apnea
has to last before an alarm is
triggered.
Apnea archive – Off
– Str./ Rec. – a recording and an event
storage is triggered automatically in
response to an apnea.
– Store (default) – a waveform segment is
stored in response to an apnea.
– Record – a recording is triggered
automatically in response to an apnea.
Determines what happens in
response to an apnea.
Selection Available settings Description
