System overview
30 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
Hemo4 pod
Infinity MPod – QuadHemo
Measures up to 4 pressures,
cardiac output, core and body
temperature.
Connects directly to the Hemo
connector of the M540 (see
information starting on
page 305).
Hemo2 pod Measures up to 2 pressures,
cardiac output, core and body
temperature.
Infinity MCable – Dual Hemo Measures up to 2 pressures.
Infinity MCable – Mainstream
CO2
Measures mainstream CO2. Connects directly to the CO2
connector of the M540 (see
page 340).
Infinity MCable – Microstream
CO
2
Measures Microstream CO2. Connects directly to the CO2
connector of the M540 patient
monitor (see page 350).
Scio Four Measures the concentration of
CO2, N2O, and anesthetic agents
(Sevoflurane, Desflurane,
Isoflurane, Halothane, and
Enflurane) in the breathing gas.
Connects directly to the CO2
connector of the M540 (see the
instructions for use Infinity Acute
Care System – Infinity M540).
Scio Four Oxi Measures the concentration of
CO
2, N2O, O2, and anesthetic
agents (Sevoflurane, Desflurane,
Isoflurane, Halothane, and
Enflurane) in the breathing gas.
Scio Four plus Measures the concentration of
CO
2, N2O, and anesthetic agents
(Sevoflurane, Desflurane,
Isoflurane, Halothane, and
Enflurane) in the breathing gas.
Scio Four Oxi plus Measures the concentration of
CO
2, N2O, O2, and anesthetic
agents (Sevoflurane, Desflurane,
Isoflurane, Halothane, and
Enflurane) in the breathing gas.
Infinity MCable – Nurse call Provides remote notification of
medium and high-priority alarm
conditions.
Connects to the PS250 / P2500
(see page 27) or to the M500
(see page 28).
Device Description Connection
