Invasive blood pressure (IBP)
320 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
Filter 8 Hz and 16 Hz (default) Selects the filter setting applied to the
invasive blood pressure signal.
Large
mean
On, Off (default) Determines whether the mean invasive
blood pressure value appears in large or
normal font.
Color Red, green, blue, yellow, light blue, purple,
orange, white.
The various invasive blood pressure
parameters have the following defaults:
– ART, GP1 to GP4 = red
– PA = yellow
– CVP = blue
– ICP, LA = purple
– RA, RV = orange
–LV = yellow
Determines the color of the waveforms,
parameter labels, and values.
ICP parameter page only
Min.
scale
On, Off (default) Allows you to select the minimum scale.
When this function is activated, the
following happens:
– The lower value is set at
–25 mmHg (–3 kPa)
– The higher value is set at 25 mmHg
(3 kPa)
–The Scale selection appears grayed
out
PA page only
Start
wedge
None Allows you to start a wedge pressure
measurement (see page 316).
Selection Available settings Description
