System configuration
454 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
6 Select the desired button or click the rotary
knob to move the new button to the menu bar.
The previous button is moved to the pop-up
window. The main menu bar changes
immediately to reflect the new selection.
7 Repeat steps 5 – 7 for additional configuration
changes to the menu bar.
To restore the default setup of the menu bar
You can restore the default setup of the menu bar
(see page 452) at any time. In the following steps,
the letters in parentheses correspond to the
diagram for the Config. buttons page (see
page 452).
1 Select the System setup... button on the main
menu bar.
2 Select the Screen setup tab (if not already
selected).
3 Select the Config. buttons tab. A password
popup appears.
4 Enter the clinical password and select the Enter
button.
5 Select the Restore config. buttons button.
Remote view Provides access to patient data from other Infinity monitors within the
same monitoring unit.
Rest ECG report Prints a diagnostic report generated from a 12-lead ECG.
Show all ECG Displays all ECG waveforms.
Standby Places the Cockpit in standby mode.
Start C.O. Starts a cardiac output measurement.
Start wedge Starts a pulmonary wedge measurement.
Split screen Turns the split screen view on and off based on the configuration. For
information about configuring the split screen view, see "Configuring the
auto view settings" on page 447.
System setup... Activates the password-protected system functions for configuring the
Cockpit.
Trend graph report Prints the contents of the graphical trends window according to the
selected Trend duration [hr] setting.
Trend table report Prints the contents of the tabular trend window according to the selected
Table interval [min] setting.
Venous stasis Activates venous-stasis mode.
Volumes... Accesses the Settings page for configuring the volume of the various
tones.
Zero all Zeroes all invasive blood pressures.
Button Description
