Troubleshooting
!!
(Any
SpO2
MCable)
SpO2 sensor
unplugged
2)
Sensor
unplugged
Parameter values
are replaced by ***
–SpO2
intermediate cable
or sensor is
unplugged
– SpO2 sensor is
unplugged from
Masimo rainbow
SET MCable
– Verify that the
cable and the
sensor are
properly
connected.
– Check for faulty
sensor.
1)
%0 is a placeholder for the parameter label SpO2.
2)
After discharging a patient or starting the device, the alarm becomes active only after a numeric value
has been received for that parameter.
3)
In the parameter field the parameter value is replaced by ***
!
(Any
Masimo
MCable)
SpO2 unrecognized
cable
3)
Unrecognized
cable
Parameter values
are replaced by ***
An incompatible cable
is connected.
– Connect the
right type of ca-
ble.
– Contact
DrägerSer-
vice
®
.
!
(Any
SpO2
MCable)
SpO2 unrecognized
sensor
Unrecognized
sensor
Parameter values
are replaced by ***
– An incompatible
Nellcor or Masimo
SET sensor is
connected.
– A reusable SpHb
Masimo rainbow
SET sensor is
connected to an
Masimo rainbow
SET MCable that
does not support
SpHb.
– Connect the
right type of
sensor.
– Contact
DrägerService
®
.
Priority Message Parameter field Problem Solution
