Checking Ventilation
1 Set knob »VT« to 0.5 L.
2 Set knob »Rate« to 12 bpm.
3 Set knob »I:E« to 1:2.
4 Set knob »Pmax« to 60 cmH2O.
5 Set knob »PEEP« to 5 cmH2O.
6 Set switch for ventilator modes to »CMV«.
7 Switch ventilator »On«.
● The ventilator will now perform an electric and
pneumatic self test.
● Display:
The software version is shown in the bottom line.
● The red alarm status light and the LCD backlighting
will be turned on briefly.
● The audible alarm will sound twice.
NOTE: For safety reasons, the audible alarm output uses
two channels which are both tested during the self test.
Therefore two audible alarms of the same duration will be
heard.
● The green DC power status light » « (DC power
ok.) will be lit continuously as long as an external pow-
er source of 11 to 13 V DC is connected.
The self test will be completed after no more than
6 seconds
● Display:
● Oxylog 2000 will now ventilate the test lung with the
set ventilation pattern.
Self test O.K.
Self test
Software xx.xx
Checking Readiness for Operation
Checking Ventilation
Operating Instructions Oxylog 2000, SW 3.n
24
1
2
D
Oxylog 2000
345
6
7
03629033
