Dräger PIR 7000 User Manual

12
Fault/complications during the calibration
Terminating the calibration
Fault – Cause – Remedy
– Fault and warning messages: see Technical Handbook, section "Faults, Cause and Rem-
edy".
Action Status Indicator Output Signal Meaning
Yellow flashes
quickly
Maintenance
signal
Device has an error or has
detected complications.
Attention: Turn off the calibration gas.
Remove calibration adapter PIR 7000.
Place the magnetic
wand to marking
» 0 « when calibrat-
ing the zero point or
to » S « during span
calibration.
Green and yellow are
on
Maintenance
signal
Error display message is
acknowledged.
Remove the mag-
netic wand.
Green/yellow flash
alternately and
slowly
Maintenance
signal
The measuring mode is acti-
vated with previous settings
for zero point and/or sensitiv-
ity.
Action Status Indicator Output Signal Meaning
Attention: Turn off the calibration gas.
Remove calibration adapter PIR 7000.
Place the magnetic
wand to marking
» S « when calibrat-
ing the zero point or
to » S « during span
calibration.
Yellow flashes
quickly (for approx.
2 seconds)
Maintenance
signal
The device has detected a
user cancellation.
Green and yellow are
on
Maintenance
signal
The device acknowledges the
termination.
Remove the mag-
netic wand.
Green/yellow flash
alternately and
slowly
Maintenance
signal
The measuring mode is acti-
vated with previous settings
for zero point and/or sensitiv-
ity.
NOTICES:
The calibration can be cancelled at any time by placing the magnetic wand onto the
marking » S « when calibrating the zero point or on » 0 « during a span calibration.
The individually selected span gas concentration may deviate from the span gas
concentration set at the factory. This must be taken into consideration during span
calibration and must be subsequently entered on the calibration label of the
device.
How to Dispose of the Instrument
From August 2005, regulations apply to the whole of the EU for the disposal of electri-
cal and electronic devices; these regulations are set in the EU Directive 2002/96/EG
and in national laws relating to this device.
Special collection and recycling possibilities have been established for private households.
However, since the instrument has not been registered for use in private households, it can-
not be disposed of as special household waste. For disposal, it can be sent back to your
national Dräger Safety Sales organisation; if you have any questions requiring disposal,
then please contact this location.
Configuration of the gas transmitter.
To individually configure a device with the standard configuration, use a PC and the CC
Vision software GDS (refer to the Technical Handbook).
In delivery state, the following configuration is set (provided that this is not a built-to-order
unit):
Configuration: Dräger PIR 7000 Dräger
Type 334 Type 340 PIR 7200
Conversion table %LEL Category 1
based on NIOSH
– – –
Measured gas
Unit
Methane
%LEL
Propane
%LEL
Carbon dioxide
% vol
Measuring range 0 ... 100 %LEL 0 ... 100 %LEL 0 ... 10 % Vol
Calibration gas
Unit
Methane
%LEL
Propane
%LEL
Carbon dioxide
% vol
Calibration gas concentration 50 %LEL 4 % vol
Maintenance signal 3 mA
Fault signal <1.2 mA
Beam block warning (inactive) 2 mA

Dräger PIR 7000 Specifications

General

Detection Principle	Infrared (IR)
Pressure Range	700 to 1300 hPa
Ingress Protection	IP66/67
Gases Detected	Hydrocarbons
Measurement Range	0 - 100 %LEL (Lower Explosive Limit) or 0 - 100 vol.%
Operating Temperature	-40 to +65 °C
Output Signal	4-20 mA
Housing Material	Stainless steel
Certifications	ATEX, IECEx, UL, CSA
Response Time	t90 ≤ 4 s
