Dräger Polytron Pulsar 2 User Manual

Electrical Installation
12
Dräger Polytron Pulsar 2 maximum permissible power cable lengths
The following tables give the maximum cable lengths for differing worst case power supply voltages and core sizes.
In using this information please note that the worst-case (lowest possible) supply voltage should be used not the nominal stated.
The lengths stated are determined by the power supply cores. If cable size and distance become excessive it may be more economic to
install a local power supply. There is no practical limit on the distance for the signal cables, although the 4-20 mA loop resistance is lim-
ited to 500 Ω total.
Cable run in metres: To both Transmitter AND Receiver
Worst case supply: 20V 21V 22V 23V 24V 25V 26V...32V
1 mm
2
:74 98 123 147 172 197 221
1.5 mm
2
: 111 147 184 221 258 295 332
2.5 mm
2
: 184 246 307 369 430 491 553
4 mm
2
: 295 393 491 590 688 786 885
18 AWG: 61 81 101 121 142 162 182
17 AWG: 77 102 128 153 179 204 230
16 AWG: 96 129 161 193 225 257 289
15 AWG: 122 162 203 243 284 324 365
14 AWG: 153 205 256 307 358 409 460
13 AWG: 193 258 322 387 451 516 580
12 AWG: 244 325 407 488 569 650 732
11 AWG: 308 410 513 615 718 820 923
10 AWG: 388 517 646 776 905 1034 1164
Cable run in metres: To Transmitter only
Worst case supply: 20V 21V 22V 23V 24V 25V 26V...32V
1 mm
2
: 114 152 189 227 265 303 341
1.5 mm
2
: 170 227 284 341 398 455 511
2.5 mm
2
: 284 379 473 568 663 758 852
4 mm
2
: 455 606 758 909 1061 1212 1364
18 AWG: 94 125 156 187 218 249 281
17 AWG: 118 157 197 236 275 315 354
16 AWG: 149 198 248 297 347 397 446
15 AWG: 188 250 313 375 438 500 563
14 AWG: 236 315 394 473 552 631 709
13 AWG: 298 398 497 596 696 795 895
12 AWG: 376 501 627 752 877 1003 1128
11 AWG: 474 632 790 948 1106 1265 1423
10 AWG: 598 797 997 1196 1395 1595 1794
