Dräger X-plore 8000 User Manual

4 X-plore 8000
00233412.eps
J
X-plore 8000 Standard Charger
IP 30
T50
Input: 15 V / 4 A
Output: 9 - 12,6 V / 4 A
Dräger Safety AG & Co. KGaA, 23560 Lübeck, Germany Made in China
X
Part-No. : R59580
Serial-No. : AREE-0001
1 92
4
12
5
67 15 13
9
10
11
14
X
0158
IP 65
EN 12941
EN 12942
Dräger Safety AG & Co. KGaA, 23560 Lübeck, Germany Made in Germany
X-plore 8000
Standard Battery
Part-No. : R59565
Serial-No. : AREE-0001
Rechargeable Li-Ion Battery 10,8 V; 3,35 Ah; 36 Wh
Must be recycled or disposed of properly
Caution: Charge with dedicated charger only
May explode if damaged or disposed of in fire
Do not short circuit
1 17
9
10
11
8
23
6
4
5
16
7
I
H
0681
0158
IP 65
EN 12941
EN 12942
FCC ID: X60-XPLORE8500
IC: 5895F-XPLORE8500
CAN ICES-3 (B)/NMB-3(B)
Part-No. : R59500
Serial-No. : ARJC-0001
X-plore 8500 (IP)
Made in Germanywww.draeger.com
Dräger Safety AG & Co. KGaA
23560 Lübeck, Germany
1
2
3 3
4
5
67
8
9
10
11

Dräger X-plore 8000 Specifications

General

Product Type	Powered Air-Purifying Respirator (PAPR)
Protection Class	TH3
Charging Time	Approximately 4 hours
Air Flow	Minimum 170 l/min
Display	LCD with status information
Filter Type	Particle filters, gas filters, or combination filters (depending on the application)
Alarm	Visual and audible alarms for low battery
Approvals	EN 12941
Battery Life	Up to 4-20 hours (depending on battery and operating conditions)
