Vigor300B Series User’s Guide
65
packets.
LAN Profile
Display which LAN profile used for the local device.
IP
Display the private IP address for such profile.
Mask
Display the subnet mask for such profile.
H
H
o
o
w
w
t
t
o
o
a
a
d
d
d
d
a
a
n
n
e
e
w
w
I
I
P
P
R
R
o
o
u
u
t
t
i
i
n
n
g
g
p
p
r
r
o
o
f
f
i
i
l
l
e
e
1. Open LAN>>IP Routing.
2. Click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item Description
Profile
Type the name of the IP routing profile.
Enable This Profile
Check this box to enable such IP routing profile.
WAN Profile
Choose one of WAN profiles for sending data out.
LAN Profile
Choose one of LAN profiles for the local device.
IP
Type the private IP address for such IP routing profile.
Mask
Use the drop down list to choose the subnet mask for such IP
routing profile.
