Vigor300B Series User’s Guide
110
4
4
.
.
5
5
.
.
1
1
I
I
P
P
O
O
b
b
j
j
e
e
c
c
t
t
For IPs in a limited range usually will be applied in configuring router’s settings, we can
define them with objects and bind them with groups for using conveniently. Later, we can
select that object/group that can apply it. For example, all the IPs in the same department can
be defined with an IP object (a range of IP address).
This page allows you to specify certain IP address, range of IP addresses or subnet mask as
an object which will be applied in Firewall.
Each item will be explained as follows:
Item Description
Add
Add a new profile.
Edit
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Delete
Remove the selected profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
Refresh
Renew current web page.
Profile Number Limit
Display the total number (256) of the object profiles to be
created.
Profile
Display the name of the profile.
Interface
Display the interface of the IP Object.
Address Type
Display the address type (single, range or subnet) for such
profile.
