VigorAP 700 User’s Guide
27
Band Please select the wireless band you wish to use. By selecting
different band setting, you’ll be able to allow or deny the wireless
client of a certain band.
If you select 2.4GHz (B), 2.4GHz (N), or 2.4GHz (G), only wireless
clients using the wireless band you select (802.11b, 802.11n, or
802.11g) will be able to connect to this access point.
If you select 2.4GHz (B+G), then only wireless clients using
802.11b and 802.11g band will be able to connect to this access
point.
If you want to allow 802.11b, 802.11g, and 802.11n clients to
connect to this access point, select 2.4GHz (B+G+N).
MAIN SSID Please input the SSID (the name used to identify this VigorAP 700)
here. You can input up to 32 alphanumerical characters. PLEASE
NOTE THAT SSID IS CASE SENSITIVE.
Multiple SSID The access point supports multiple SSID function; up to four SSIDs
can be set. If you want to configure additional SSIDs, please click
this button. For detailed descriptions of the function, please refer to
Section 2-4-1-1.
Channel Please select a channel number you wish to use. The channel
number must be same with another VigorAP 700 you wish to
connect
Associated Clients
Click Show Active Clients button and a new popup window will
appear which contains the information about all wireless clients
connected to this access point. You can click Refresh button in
popup window to keep information up-to-date.
Associated WDS AP
Click Show WDS AP button and a new popup window will appear
which contains the information about all WDS AP connected to this
access point. You can click Refresh button in popup window to keep
information up-to-date.
MAC address 1-4 Please input the MAC address of the VigorAP 700 you wish to
connect.
After you finish with setting, please click Apply, and the following screen will be displayed:
