Dremel 3D45 User Manual

Unpacking
11
1. Place box on table, cut tape, and open.
2. Remove top insert.
3. Remove 3D45 and place on table.
4. Open lid and remove top insert.
5. Raise build platform by lifting from both sides.
6. Open door and remove middle insert.
7. Remove bottom insert.
Tip: Keep packaging for future transportation
and storage.
DM 2610047405AB 03-18_3D45 3/27/18 9:51 AM Page 11

Dremel 3D45 Specifications

General

Layer Resolution	50 - 300 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Max Extruder Temperature	280 °C
Max Bed Temperature	100 °C
Technology	Fused Filament Fabrication (FFF)
Heated Bed	Yes
Print Speed	Up to 150 mm/s
Enclosed Print Chamber	Yes
Connectivity	USB, Wi-Fi, Ethernet
Supported Filaments	PLA, Nylon, PETG, ECO-ABS
Printer Dimensions	515 x 406 x 403 mm
Display	Full-color touchscreen
Power Requirements	100 - 240 V, 50/60 Hz
