Specifications
7
BUILDING
Extruder: single extrusion
E
xtruder Temperature: Up to 280 C, 536 F
Build Platform Temperature: Up to 100 C,
212 F
Operating Interface: 4.5” full color IPS touch
screen
Maximum Build Volume: 10” x 6” x 6.7”
(255mm x 155mm x 170mm)
Layer Thickness: 50 microns (0.05 mm)
Filament Types and Colors: See
www.digilab.dremel.com for color choices
Internal Storage: 8GB
External Storage: USB flash Drive
WEIGHT & DIMENSIONS
Weight (without spool): 19.4 kg (42.8 lb)
Dimensions: 20.25” x 16” x 15.9” (515mm x
406mm x 394mm)
FILAMENT
ONLY works with Dremel 1.75mm filament
FILAMENT STORAGE
All polymers degrade with time. Do not
unpack until filament is needed. Filament
should be stored at room temperature:
16-29° C (60-85° F) and in dry conditions.
SOFTWARE
Dremel 3D45 comes with complimentary file
slicing software for Windows and Mac OSX.
This application converts your 3D digital files
into buildable files.
SUPPORTED OPERATING SYSTEMS
• Apple
®
Mac
®
OS
®
X v10.9 or later
(
Mavericks)
• Microsoft
®
Windows
®
7 SP1
• Microsoft
®
Windows
®
Window 8, 8.1
• Microsoft
®
Windows
®
Window 10
MINIMUM SYSTEM SPECIFICATIONS
FOR PRINT STUDIO
• CPU: 64-bit processor (32-bit not
supported)
• Memory: 3 GB RAM (4 GB or more
recommended)
• Disk space: ~2 GB free disk space for
installation
• Display card: 1,024 MB GDDR RAM or
more. Microsoft
®
Direct3D
®
11 capable
graphics card or higher
• Pointing Device: three-button mouse
ELECTRICAL REQUIREMENTS
3D45 input rating: 100-240V, 47-60Hz,
0.85-2.3Amps
OPERATING ENVIRONMENT
Room Temperature: 16-29° C (60 - 85° F)
Level workspace
Dry workspace environment
