Getting Ready to Build
LEVELING BUILD PLATFORM
Do not touch the extruder
tip or heated build platform
during Dremel 3D45 operation or until it
has cooled down to at least 60°C (140°F).
Contact with the extruder tip or build platform
during or after operation before tip and build
plate has cooled may result in personal injury.
It is important you level the build platform
every time you reinstall the build platform to
ensure that the build platform is evenly
spaced from the extruder head. Not leveling
the build platform may cause objects to not
build properly.
1. Tap “Level” on 3D45’s touch screen.
2. The extruder and build platform will move
into position to level the build platform.
3D45 will first check level at the back
center of the build platform. The two
knobs under the build platform are used to
raise and lower the build platform on the
left and right. The extruder contains a
sensor that detects if the bed is level, no
additional tools are necessary.
3. The touch screen will indicate if your build
platform is too high or too low. If the build
platform is too high, adjust the appropriate
knob by rotating right until you hear a
“beep” and the touch screen indicates that
it is ready to verify that the bed is level.
4. If the build platform is too low, adjust the
knob by rotating left until you hear a
“
beep” and the touch screen indicates that
it is ready to verify that the bed is level.
5. Tap “Verify” to check the bed level. If
further adjustment is needed the touch
screen will indicate the direction, if the
level is correct, the extruder will move to
the next point and the level process can
be repeated.
6. Repeat steps 3-5 for the second position,
when you bed is fully level the extruder
will automatically move to the calibration
position and complete the leveling
process.
!
WARNING
