XT SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
INSTALLATION
Dispersion:
• Place the dispersion assembly such that absorption will occur:
– before the intake of a high effi ciency fi lter, because the fi lter can remove
the visible moisture and become waterlogged;
– before coming in contact with any metal surface;
– before fi re or smoke detection devices;
– before a split in the duct; otherwise, the dispersion assembly can direct
more moisture into one duct than the other.
• When draining dispersion condensate to an open drain, provide a 1"
(25 mm) air gap between the condensate drain piping and the drain.
Locate the gap only in spaces with adequate temperature and air movement
to absorb fl ash steam; otherwise, condensation may form on nearby
surfaces.
WARNING
Hot surface and steam hazard
Dispersion assembly and steam hose or
tubing can contain steam, and surfaces
can be hot. Discharged steam is not
visible. Contact with hot surfaces or air
into which steam has been discharged
can cause severe personal injury.
Selecting the dispersion assembly location
