XT SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Capacities, line currents, and fusing
Table 4-1:
Line currents and recommended fusing for XT Series humidifiers
Model Nominal steam capacity
kW Phase Volts Maximum line current (amps) Recommended fusing (amps)
XTP lbs/hr kg/h
002 5 2 1.7 1
120 17 25
208 10 15
230 8 15
240 8 15
003 10 5 3.3
1
208 19 25
230 17 25
240 17 25
277 14 20
400 10 13
480 8 15
600 7 10
3
208 11 15
240 10 15
400 6 10
480 5 10
600 4 10
006 18 8 6.0
1
208 35 45
230 31 40
240 30 40
277 26 35
400 18 25
480 15 20
600 12 15
3
208 20 25
240 17 25
400 10 13
480 9 15
600 7 10
010 30 14 10.0 3
208 33 45
240 29 40
400 17 25
480 14 20
600 12 15
017 50 22 16.5 3
208 55 70
240 48 60
400 29 40
480 24 35
600 19 25
025 75 34 25.0 3
400 43 63
480 36 50
600 29 40
033 100 45 33.3 3
400 58 80
480 48 70
600 39 50
042 125 57 41.7 3
400 72 100
480 60 80
600 48 70
048 143 65 47.8 3
400 80 100
480 69 90
600 55 70
050* 150 68 50.0 3
400 2 x 43 2 x 63
480 2 x 36 2 x 50
600 2 x 29 2 x 40
067* 198 90 66.7 3
400 2 x 58 2 x 80
480 2 x 48 2 x 70
600 2 x 39 2 x 50
083* 250 113 83.3 3
400 2 x 72 2 x 100
480 2 x 60 2 x 80
600 2 x 48 2 x 70
096* 287 130 95.7 3
400 2 x 80 2 x 100
480 2 x 69 2 x 90
600 2 x 55 2 x 70
* These models have two steam cylinders and require independent service connections.
