XT SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Accessories
Table 61-1:
Accessories
Description Part No.
Steam hose, 1" (DN25) x 10' (3 m), for remote XT steam blower 305400-100
Steam hose, 1½" (DN40) x 10' (3 m), wire-reinforced 305400-010
Steam hose, 2" (DN50) x 10' (3 m), wire-reinforced 305560-0010
Condensate hose, 1/4" (DN8) x 13' (4 m), for remote XT steam blower 305400-150
Drain hose cuff, 1" (DN25) I.D. x 12" (305 mm) long 305389-012
Hose clamp, 1" (DN25) I.D. 700560-100
Hose clamp, 23 mm, spring band 700560-023
Hose clamp, 19 mm, spring band 700560-019
Hose clamp, 1½" (DN40) I.D. 700560-150
Hose clamp, 2" (DN50) I.D. 700560-200
Kit, drip tee, 304 stainless steel, 1½" (DN40) 191071-001
Humidistat, duct high limit, HC-201 405850-201
Humidistat, room, HC-101 405870
Humidity transmitter, duct, 2% RH DSB 405884-009
Humidity transmitter, room, 2% RH 405883-008
Switch, airfl ow, AFS-112-150, electric 406190
Kit, Y connector; Models XTP 033, 042, and 048 (see Figure 24-1)
• 1 Y connector, stainless steel, 1½" x 2" (DN40 x DN50)
191070-101• 2 steam hoses, 1½"(DN40), 12" (305 mm) long
• 4 hose clamps
Kit, Y/tube connectors; Models XTP067 through 096 (see Figure 24-1)
• 2 Y connector kits 191070-101
• 1 fl anged tube connector, stainless steel, 3" (DN80) 162825-202F
Kit, tube connector; Model XTP050 (see Figure 24-1)
• 1 tube connector, stainless steel, 1½" x 2" (DN40 x DN50)
191070-002• 1 hose cuff, 2" (DN50), 6" (152 mm) long
• 2 hose clamps
Kit, tube reducer; Models XTP 002 through 006 (see Figure 23-1)
• 1 tube reducer, stainless steel, 1" x 1½" (DN25 x DN40)
191070-100• 1 steam hose, 1" (DN25), 12" (305 mm) long
• 2 hose clamps
Kit, tube Y connector; Model XTP 025 (see Figure 23-1)
• 1 Y connector, 1.5" x 1.5" x 1.5"(DN40 x DN40 x DN40)
191070-102• 1 steam hose, 1.5" (DN40), 12" (305 mm) long
• 2 hose clamps
