XT SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
Table 59-1:
Models XTP 050 through 096 replacement parts
Item Description Part No.
1
Transformer, 120V, 24V SEC - QC 408965-101
Transformer, 208/240/480V, 24V SEC - QC 408965-102
Transformer, 277V, 24V SEC - QC 408982-101
Transformer, 600V, 24V SEC - QC 408986-101
Transformer, 230/400, 24V SEC - QC 408985-101
2 Contactor 407010-*
3 Plug, high water sensor 530010-105
4
Board, current sensing, 400/480 V 530013-002
Board, current sensing, 600 V 530013-003
Board, current sensing, 208/230/240/277/400 V 530013-004
Board, current sensing, 230/400 V (Model XTP096 only) 530013-005
5 Display board, Vapor-logic controller 408495-004
6 Main board, Vapor-logic controller 183504-014
7
Kit, electrode wiring
(plugs with wires: 1 red, 1 black, 1 white)
194625-001
Kit, electrode wiring, extended
(plugs with wires: 1 red, 1 black, 1 white)
194625-002
8*
Kit, cylinder, XT-75/150, XT-025/050, 380V, 3P 194601-023
Kit, cylinder, XT-75/150, XT-025/050, 400-600V, 3P 194601-025
Kit, cylinder, XT-100/200, XT-033-096, 380/400V, 3P 194601-026
Kit, cylinder, XT-100/200, XT-033-096, 480/600V, 3P 194601-028
9 Strainer, cylinder 531006
10 Drain valve assembly (see parts in Figure 51-1) 194610-001
11 Fill valve assembly Models XTP 025 through 096 194623-002
12 Kit, fi ll cup extension (see parts in Figure 11-1) 194605-101
13 Fuse 2A 600V ATM 406740-014
14 Switch interlock with override 530010-102
15
Fuse 40A 480V AG (XTP 083, 480 volt only) 406720-040
Fuse 50A 480V AG (XTP 096, 480 volt only) 406720-050
16 Switch auxiliary GE ECLA211S 407001-024
*
See cylinder Part No. on your XT Series humidifi er.
MAINTENANCE
Replacement parts
