22
LT-2334
FIGURES, DIAGRAMS AND PARTS LIST
PARTS AND ACCESSORIES
125 POC
Part Description Part #
1 Oxygen Outlet Port w/Bacteria Filter 125D-610
2 Control Panel Label 125D-623
3 Cover Plate N/A
4 Case Screws (6) 125D-621
5 Cover/Case N/A
6 Printed Circuit Board N/A
7 Compressor N/A
8 Accumulator Tank N/A
9 Sieve Beds 125D-619
10 Cooling Fan N/A
11 Purge Valve N/A
12 Accumulator Manifold N/A
13 Switching Manifold N/A
14 Dispense Valve N/A
15 OSD (oxygen sensing device) N/A
16 Intake Filter (Compressor Silencer) N/A
ACCESSORIES
17 Battery 125D-613
18 Power Supply (120 Watt) DV68-620
19 AC Power Cord - USA DV51D-606
20 AC Power Cord – CE DV51D-607
21 AC Power Cord - UK DV51D-608
22 AC Power Cord – Australia DV51D-609
23 AC Power Cord - China DV51D-614
24 DC Power Cord DV6X-619
External Battery Charger – US 125CH-613
External Battery Charger – CE 125CH-614
External Battery Charger - UK 125CH-615
Carrying Case 125D-670
There are many types of oxygen tubing and cannulas. Certain accessories
may impair the device’s performance. Use only standard nasal cannula with
25’ or less of crush-proof oxygen tubing with this concentrator. Do not use
pediatric (low-ow) nasal cannula or mask. Your homecare provider should
also give you advice on the proper usage, maintenance, and cleaning.
