VF61 Console Monitor Indications
Code
No.
LCD indication Monitor Indications Unit Remarks
0 Fout Output frequency Hz
1 Fref Reference frequency Hz
2 Iout Output current A
3 Vout Output voltage V
4 Torq out Torque (torque current) %
Current for the same phase as the output voltage is
indicated.
5 Vdc DC voltage V
6 Motor Speed Synchronous speed rpm
For ASR operation, number of rotations indicated. For other
operation, frequency obtained based on the number is
indicated.
7 OL counter Overload counter %
When the rated motor current is exceeded, the counter starts
counting. After this, when the counter reaches 100%, the
overload protection activates. (When OL.SET=100%)
8 Line Speed Line speed - Value obtained in No. 93 is indicated.
9 I1 term check Input terminal check 1 bit 1 is indicated by terminal block on.
10 I2 term check Input terminal check 2 bit 1 is indicated by terminal block on.
11 0- term check Output terminal check bit 1 is indicated by terminal block on.
15 ROM version ROM version -
"XX-XX" of ROM software version VF61-XX-XX is displayed
through conversion of alphabetic characters into numberic
characters like A=0, B=1, and so forth.
17 Trouble moni Protection history -
The contents of the last 5 protection and the current and
voltage at the time of the protection are indicated.
