D61532 110vac Input Signal Isolator Board
P/N 10561532 PCB Revision 1
D61533 24vac Input Signal Isolator Board
P/N 10561533 PCB Revision 1
For use with Drivecon VF6100 Standard or VF61V/S Flux Vector series of variable
frequency drives
Introduction
The D61532 / D61533 Input Signal Isolator Boards are for use with Drivecon VF6100 Standard or
VF61V/S Flux Vector series of variable frequency drives. They are designed to accept external 110vac or
24vac inputs from switch or relay contacts. The D61532 will accept 110-120vac signals and the D61533
will accept 24vac input signals. The D61532 will not function with 24vac input signals and the D61533 will
be damaged if used with 110vac input signals.
Either model of input isolator boards will provide direction [run forward / run reverse] and up to 4
additional preset speeds. Another input is assigned as an external fault reset. Two additional inputs can be
assigned individual functions from a list of 16 programmable functions. Also available are two separate
relay outputs that can be individually assigned separate functions from a list of 15 programmable functions.
Each input has a red LED indicator that illuminates when the input is active and is optically isolated from
the VFD main control board. Each programmable relay output has a green LED indicator that illuminates
when the output is active. Each relay has “dry” form C contacts available at the terminal strip for external
use. There are also two slowdown travel limit switch inputs, one for each direction that will cause the VFD
to slow down to the programmed minimum speed level in the affected direction. Normal travel and speed
control are still available for the other direction. The slowdown limit switch should open to cause the VFD
to slowdown. A yellow LED indicator is illuminated when the limit switch is closed indicating normal
travel and speed are available.
Table 1 Basic Program List for VF6100 Standard Variable Frequency Drive
D61532 / D61533 terminal
No.
Code Group Code number to assign
function
Code Group / Code No.
to set value
1 Fwd Basic Setting Code 63 Code 0
2 Rev Basic Setting Code 63 Code 0
3 2
nd
speed Sp.Set 1 Code 74 Basic Setting / 3
4 3
rd
speed Sp.Set 1 Code 75 Basic Setting / 4
5 4
th
speed Sp.Set 1 Code 75 SP1.Set 1 / 86
6 5
th
speed Sp.Set 1 Code 76 SP1.Set 1 / 87
7 Prog input 1 Sp.Set 1 Code 77 MFI 4 assign
8 Prog input 2 Sp.Set 1 Code 78 MFI 5 assign
9 Prog input 3 Sp.Set 1 Code 79 MFI 6 assign
10-12 Prog output 1 Sp.Set 1 Code 66 MFO 1 assign
13-15 Prog output 2 Sp.Set 1 Code 67 MFO 2 assign
16 110vac neutral Not programable 110 v neutral only For 110v control return
17 Fwd Slowdown Limit Basic Setting Code 0
18 Rev Slowdown Limit Basic Setting Code 0
26
