Table 2 Basic Program List for VF61V/S Flux Vector Variable Frequency Drive
D61532 / D61533 terminal
No.
Code Group Code number to assign
function
Code Group / Code No.
to set value
1 Fwd Basic Setting Code 54 Code 0
2 Rev Basic Setting Code 54 Code 0
3 2
nd
speed Sp.Set 1 Code 32 PGM.Mode/17
4 3
rd
speed Sp.Set 1 Code 33 PGM.Mode/18
5 4
th
speed Sp.Set 1 Code 33 PGM.Mode/19
6 5
th
speed Sp.Set 1 Code 34 PGM.Mode/20
7 Prog input 1 Sp.Set 1 Code 35 MFI 4 assign
8 Prog input 2 Sp.Set 1 Code 36 MFI 5 assign
9 Prog input 3 Sp.Set 1 Code 37 MFI 6 assign
10-12 Prog output 1 Sp.Set 1 Code 38 MFO 1 assign
13-15 Prog output 2 Sp.Set 1 Code 39 MFO 2 assign
16 110vac neutral Not programable 110 v neutral only For 110v control return
17 Fwd Slowdown Limit Basic Setting Code 0
18 Rev Slowdown Limit Basic Setting Code 0
Specifications
Table 3
110v input level 100 vac minimum 125 vac maximum ½ watt burden - 5mA per
input.
Red LED illuminates on
input activation
110v input isolation 2000 VRMS Optically isolated
Relay output 1 Form C contacts rated at
250 vac @ 2 amps
terminal 10 - N/O
terminal 11 - N/C
terminal 12 - COM
Green LED illuminates
on relay pick-up
Relay output 2 Form C contacts rated at
250 vac @ 2 amps
terminal 13 - N/O
terminal 14 - N/C
terminal 15 - COM
Green LED illuminates
on relay pick-up
Power requirements 15 vdc @ 75 mA
from VFD main control
board
No external DC power
required
Temperature Range 0 - 50° C
Humidity Less than 90 %
Altitude Less than 3000 ft
Storage temperature -20° C to +70° C
Wiring Diagram
Refer to Drivecon Drawing Number 61532CON.VCD for electrical connection information.
CAUTION: This solid state isolator will be damaged if the output (connection to
drive terminals) are wired in parallel with any external circuits.
27
